Plazmaman Pro Series R32 R33 R34 GTR Intercooler 100mm / 1300+hp Rated

Plazmamans Lightweight Tube & Fin replacement intercooler is designed to suit the Nissan Skyline GT-R R32-R34 models.

From factory, the RB26DETT powered GT-R Nissan Skylines come out with a large size front mount intercooler as standard equipment, however they start to lose their efficiency at 450+ engine horsepower levels. Plazmamans tube and fin upgrade intercooler are rated to make efficient power to 1300hp+ at the flywheel, and still appears like a factory intercooler from outside the vehicle. This intercooler is ideal for vehicles making 1000+awhp on high boost pressures, utilizing huge 80mm end tank outlets.

Standard Specifications;
1000-1300+ hp Rated Competition Spec Intercooler
600x300x100mm.
Lightweight tube & fin race spec core design.
Large sweeping end tanks as per factory appearance and OEM 80mm outlets (other sizes available also).
8.4kgs total weight.
As used and proven in many high horsepower applications

For R34 V-spec will need to add the intake temp sensor provision for it to work with the OEM setup.

Please be aware that due to the large 100mm thickness and nature of the Competition Intercooler, some sacrifices have to be made to flow horsepower. Some minor plastic trimming at rear of the front bar will be required depending on model. Frontal appearance of the bar will not be affected. Some custom bracket mods might have to be done also depending on model and the location/tilt of the cooler required.
